Functional Specifications
2.5 I/O Ports
Rev.1.00 Oct 09, 2008 2-8
REJ11J0021-0100
2
Table 2.5.1 I/O Port Features
SH7137 Expansion connectors
No. Pin Name J8 J9 J10 J11 J12
Remarks
2 PE21/WRL/TIOC4DS/TRST √
*
4 PE20/TIOC4CS/TMS √
*
5 PE19/RD/TIOC4BS/TDO √
*
6 PE18/CS1/TIOC4AS/TDI √
*
7 PE17/CS0/TIOC3DS/TCK √
*
8 PE16/WAIT/TIOC3BS/ASEBKAK/ASEBK √
9 PE15/TIOC4D/IRQOUT √ LED
10 PE14/TIOC4C
√
LED
12 PE13/TIOC4B/MRES √ LED
13 PE12/TIOC4A √ LED
15 PE11/TIOC3D √ LED
17 PE9/TIOC3B √ LED
18 PE10/CS0/TIOC3C √
19 PE8/A15/TIOC3A √
20 PE7/A14/TIOC2B √
21 PE6/A13/TIOC2A/SCK1 √
22 PE5/A12/TIOC1B/TXD1 √
23 PE4/A11/TIOC1A/RXD1 √
24 PE3/TIOC0D/SCK0
√
25 PE2/TIOC0C/TXD0 √ Serial
26 PE1/TIOC0B/RXD0 √ Serial
27 PE0/TIOC0A √
28 PD10/SSO √
29 PD9/SSI √
30 PD8/SCK2/SSCK √
31 PD7/D7/TXD2/SCS √ √
32 PD6/D6/RXD2 √ √
33 PD5/D5/SCK1 √
34 PD4/D4/TXD1 √
35 PD3/D3/RXD1 √
37 PD2/D2/SCK0
√
38 PD1/D1/TXD0 √
40 PD0/D0/RXD0 √
41 PB7/CS1/CRx0 √ RCAN
42 PB6/WAIT/CTx0 √ RCAN
43 PB5/A19/IRQ3/POE5/TIC5U √
44 PB4/A18/IRQ2/POE4/TIC5US √ IRQ2 SW
45 PB3/A17/IRQ1/POE1/TIC5V/SDA √ EEPROM
46 PB2/A16/IRQ0/POE0/TIC5VS/SCL √ EEPROM
47 PB1/BREQ/TIC5W √
49 PB0/BACK/TIC5WS √
51 PA15/CK/TXD1/SSO
√
52 PA14/A10/RXD1/SSI √
53 PA13/A9/SCK1/SSCK √
54 PA12/A8/SCK0/SCS √
55 PA11/A7/TXD0/ADTRG √
56 PA10/A6/RXD0 √
58 PA9/WAIT/TCLKD/POE8/TXD2 √
60 PA8/ /WRL/TCLKC/POE6/RXD2 √
61 PA7/TCLKB/POE5/SCK2/
62 PA6/RD/UBCTRG/TCLKA/POE4 √
63 PA5/A5/IRQ3/SCK1 √
65 PA4/A4/IRQ2/TXD1 √ Serial
66 PA3/A3/IRQ1/RXD1
√
Serial
67 PA2/A2/IRQ0/POE2/SCK0 √
68 PA1/A1/POE1/TXD0 √
69 PA0/A0/POE0/RXD0 √
