First Things First First Things First
Unpack and Take Inventory
Verify that the DSS ® dish box contains these parts:
• mounting foot and mast assembly
• satellite dish
• LNB (Low Noise Block converter)
• LNB support arm
• hardware packet
1 Phillips head screw
1 Retainer nut
LNB Mounting Hardware
4 Self locking nuts
4 Star washer
Reflector Hardware
1 Star washer
1 Hex head bolt
1 Self locking nut
Grounding Hardware
Dish
Mast
LNB support arm
Retainer nut
Phillips head screw
Mounting foot
Self locking nut, star
washer, hex head bolt
LNB
4 Self
locking nuts
and star washers
Don’t assemble the dish yet!
This diagram is to show you how you
will put the dish together later.
