12
Some Indoor Stuff
Connection A
Best Picture and Sound Quality
To use this connection you must have:
• TV with separate RF, audio/video, and S-Video inputs (jacks)
• VCR with RF input and output
• Coaxial, audio/video, and S-Video cables
To connect TV, VCR and antenna or cable box.
1. Connect coaxial cables as shown.
2. Connect audio/video cables as shown.
3. Connect S-Video cable as shown.
To receive DSS ® programming:
1. Tune TV to receive the S-Video output from the DSS ® receiver.
2. Tune DSS ® receiver to desired channel.
To receive off-air programming (no cable box):
1. Turn off VCR and DSS ® receiver.
2. Tune TV to desired channel.
To receive off-air programming (with cable box):
1. Turn off VCR and DSS ® receiver.
2. Tune TV to cable box output channel (usually CH2, CH3,
or CH4).
3. Tune cable box to desired channel.
To record DSS ® programming:
1. Tune TV to receive S-Video output from DSS ® receiver.
2. Tune DSS ® receiver to desired channel.
3. Set your VCR to record the DSS output channel (usually CH3
or CH4).
To view VCR programming:
1. Tune TV to VCR output channel (usually CH3 or CH4).
Cables needed for this connection:
one (1) S-Video cable, six (3) audio/
video cables. You must use RG-6
coaxial cable from the DSS
® dish to
the Satellite In jack on the DSS ®
receiver. For best picture quality, use
RG-6 coaxial cable with all coaxial
cable connections.
