14
Some Indoor Stuff
Connection B
Very Good Picture and Sound Quality
To use this connection you must have:
• TV with separate RF and audio/video inputs (jacks)
• VCR with RF input and output
• Coaxial and audio/video cables
To connect TV, VCR and antenna or cable box.
1. Connect coaxial cables as shown.
2. Connect audio/video cables as shown.
To receive DSS ® programming:
1. Tune TV to receive line output from DSS ® receiver
(often called Input 1).
2. Tune DSS ® receiver to desired channel.
To receive off-air programming (no cable box):
1. Turn off VCR and DSS ® receiver.
2. Tune TV to desired channel.
To receive off-air programming (with cable box):
1. Turn off VCR and DSS ® receiver.
2. Tune TV to cable box output channel (usually CH2, CH3,
or CH4).
3. Tune cable box to desired channel.
To record DSS ® programming:
1. Tune TV to receive line output from DSS ® receiver (Input1).
2. Tune DSS ® receiver to desired channel.
3. Set your VCR to record DSS output channel (usually CH3 or
CH4).
To view VCR programming:
1. Tune TV to VCR output channel (usually CH3 or CH4).
Cables needed for this connection:
six (3) audio/video cables. You must
use RG-6 coaxial cable from the DSS
®
dish to the Satellite In jack on the
DSS
® receiver. For best picture quality,
use RG-6 coaxial cable with all coaxial
cable connections.
