35
Testing the System
mast
5
3. Tighten the bolts on the foot so that the mast will not rotate.
4. Secure the mounting foot to the temporary stand. Try using
clamps, lag bolts, or a helper to hold the mast foot in place.
5. Place the dish assembly on the mast.
6. Make sure you have a length of RG-6 coaxial cable that will
reach from the temporary dish setup to your DSS
® receiver.
7. Push the cable through the bottom of the mast and out the
top. Pull about three (3) feet of cable out of the top. Loop
the cable and push it through the LNB support arm.
cable
CABLE
LNB support arm
mast
7
