General Description 2-27
LAN Connector LEDs
Two LAN ports (connectors) located in the back have two LEDs each.
• 100/10 LED (LAN connector 2), 1000/100/10 LED (LAN connector 1)
These LEDs show the transfer rate of the network that is being connected.
LED indications
LAN connector 1
1000/100/10
LAN connector 2
100/10
Amber Operating as 1000BASE-T. Operating as 100BASE-TX.
Off Operating as 100BASE-TX or
10BASE-T. Operating as 10BASE-T.
• LINK/ACT LED
The LINK/ACT LED shows the status of a standard network port. It is green if power is supplied
to the main unit and hub, and they are connected correctly (“LINK”). It blinks green while the
network port sends or receives data (ACT).
When the LED does not illuminate during “LINK,” check the condition and connection of
network cables. If there is nothing wrong with the cables, a defect is suspected in the network
(LAN) controller. In this case, contact your sales agent.
