7-14 Troubleshooting
POST Error Messages
Powering on the server automatically starts the self-diagnostic program, POST (Power On
Self-Test). When POST detects any error, it displays an error message and its measure on the
display unit. Follow the table below to troubleshoot such errors.
Phoenix BIOS 4.0 Release 6.0.XXXX
:
CPU=Pentium III XXX MHz
0640K System RAM Passed
0127M Extended RAM Passed
WARNING:
02B0: Diskette drive A error.
:
press to resume, to SETUP
Message indicating a floppy disk drive error
TIPS: For error messages on optional PCI board, refer to the manual provided with those
options.
On-screen error message Cause Action
0200 Failure Fixed Disk • Configuration error in Setup
menu.
• Hard disk is faulty.
• CPU module board is faulty.
• PCI module board is faulty.
• Check configuration in Setup
menu.
• Replace the hard disk.
• Replace the CPU module
board.
• Replace the PCI module
board.
0210 Stuck Key Keyboard connection error • Disconnect the keyboard
and connect it back again.
• Replace the keyboard.
• Replace the PCI module
board.
0211 Keyboard error Keyboard is faulty.
0212 Keyboard Controller
Failed
Keyboard controller is faulty.
• Check the keyboard
connection.
• Restart the server.
• Replace the PCI module
board.
0213 Keyboard locked -
Unlock key switch
Keyboard is locked. Unlock the key switch.
0220 Monitor type does not
match CMOS - Run
SETUP
Illegal monitor type is
specified. • Select "Get Default Value"
from the Setup menu.
• Clear the CMOS data.
0230 System RAM Failed at
offset
DIMM is faulty. • Replace DIMM.
• Replace the CPU module
board.
0231 Shadow RAM Failed at
offset
DIMM is faulty. • Replace DIMM.
• Replace the CPU module
board.
