2-14 General Description
PCI Module
Group 1 and group 2 have the same configuration.
1
Cooling fan
2
Power unit
3
AC inlet (in the back)
The AC cable in the module which is connected to the AC inlet cannot be used for other
purposes.
4
Backpanel connector (in the back)
5
PCI module board
6
Video board
7
PCI riser card
8
PCI board retention bracket
9
SCSI backboard
