CHAPTER 2 INSTALLATION
– 66 – NWA-008869-001 Rev.1.0
atch2001.fm
Example of MDF Cross Connection for PN-30DTC-C (DTI)
Continued on next page
PIM0
J P MDF PN-RTA
AP04
RA
RB
TA
TB
9
34
10
35
9
34
10
35
RA
RB
TA
TB
LTC1
RECEIVE
TRANSFER
TRANSFER
J P
AP05
RA
RB
TA
TB
17
42
18
43
17
42
18
43
RA
RB
TA
TB
LTC1
RECEIVE
To digital private network (E1)
WAN
E1 Network cable
PZ-M650 (DTI)
PN-30DTC-C (DTI)
INSTALLATION PROCEDURE
