42 Chapter 5 Connecting the server to power
Figure 13
Example setup of 600r with peripherals
To connect the 600r server to power
WARNING
Risk of personal injury and risk of hardware failure
You must connect the power outlets that are used by the CallPilot
server and its peripheral devices to the same single-point ground
reference as the one used by the switch with MGate cards
connected to the CallPilot server.
If this requirement is not met, power transients can cause
personal injury, hardware failure, or both. For more information
about single-point grounding requirements, seeInstallation and
Configuration Task List (NN44200-306).
Nortel CallPilot
600r Server Hardware Installation
NN44200-307 01.03 Standard
5.0 14 May 2008
