34 Chapter 4 Installing the server and peripheral devices
power switch. Two MAC addresses are shown on the label. The CLAN
MAC address is the top MAC address, labeled MAC1, while the ELAN MAC
address is labelled MAC2.
To connect the server to the Nortel server subnet
Step Action
1 On the back of the server, locate the CLAN connector.
Note: The CLAN connector is labeled 1 on the rear panel of the
600r. For the connector location, see the diagram on
Figure 7
"Rear panel" (page 29) , Label I.
2 Connect an RJ-45 network cable from the CLAN Ethernet switch
or hub to the CLAN connector.
Note: When connecting the optional Nortel server subnet, do
not connect to the network until you ensure that CallPilot has
the latest antivirus software. Do not install third-party antivirus
software unless approved by Nortel. For information about the
antivirus software packages that are approved by Nortel for
CallPilot, see Product Bulletin P-2007-0101-Global : CallPilot
Support for Anti-Virus Applications. Also, ensure your CallPilot
application resides behind your network firewall.
—End—
What is next?
Continue with "Installing the Nortel software feature dongle" (page 34) .
Installing the Nortel software feature dongle
The software feature key is a security device that stores the unique serial
number of the server. The feature key is embedded in the Nortel software
feature dongle that plugs in to a USB port on the rear panel.
The following diagram shows the dongle plugged in to the back panel of
the server:
