Connecting peripherals to the server 31
WARNING
The terminator is not a hot-plug device. If you replace the
terminator, or if you add an external SCSI peripheral, the server
must be powered off. If you replace the terminator or add a SCSI
peripheral when the system is on, the system can crash.
Step Action
1 Power off the server and the tape drive.
Note: For the proper shutdown procedure, see the chapter,
"Starting up and shutting down the CallPilot server" in Installation
and Configuration Task List (NN44200-306).
2 Set the SCSI ID push button switch, located on the back of the tape
drive, to 6.
3 Connect the external SCSI tape drive to the SCSI port in the rear
panel, Label C on the rear panel diagram, as shown in
Figure 7
"Rear panel" (page 29) .
Note: You must remove the server terminator before you
connect the tape drive to the server. Keep the server terminator
in a safe place, as you may need the server terminator when
you want to use the server, and the tape drive is not available to
terminate the SCSI bus.
Figure 8
SCSI tape drive with terminator
