Page 32

Chapter 4 Installing the server and peripheral devices

Install the SCSI tape drive terminator to the back of the SCSI tape
drive, as shown in Figure 8, under the label Tape drive terminator.

Note: Nortel does not recommend connecting older SCSI
protocol terminators, as this can affect server performance.

Plug the tape drive into the same single point ground and A/C power
as the rest of the system.

Power on the tape drive.

Note: Your 600r comes with the tape drive drivers preinstalled.
During the loading of Windows, the system automatically detects
the tape drive and loads the drivers that are necessary to operate
the tape drive. When system startup is complete, the tape drive
is ready for use.

—End—

What is next?

Connect the server to the ELAN subnet and Nortel server subnet (if
applicable).

Note: Before you connect to the network, ensure that CallPilot has the
latest antivirus software. Do not install third-party antivirus software
unless approved by Nortel. For information about the antivirus software
packages that are approved by Nortel for CallPilot, see Product Bulletin
P-2007-0101-Global : CallPilot Support for Anti-Virus Applications. Also,
ensure your CallPilot application resides behind your network firewall.

Connecting the server to the ELAN subnet

Connect the CallPilot server to the Meridian 1 switch or CS 1000 system
using the ELAN subnet.

ATTENTION

For important considerations about using the ELAN subnet in your network, see
the Planning and Engineering Guide (NN44200-200).

To connect the server to the ELAN subnet (Meridian 1 or CS 1000 only)

Step

Action

On the back of the server, locate the ELAN Ethernet connector.

Nortel CallPilot

600r Server Hardware Installation

NN44200-307

01.03

Standard

5.0

14 May 2008
