Chapter 3 Preparing for installation
Step
Description
Check
2
Unpack the server and ensure you have all the items you
need (see
"Unpacking the 600r server" (page 23)
).
Complete the following checklists that are provided in the
Installation and Configuration Task List (NN44200-306):
•
CallPilot software media and documentation checklist
•
CallPilot server hardware checklist
__
3
Remove the top cover and inspect the interior (see
"Inspecting the interior of server" (page 24)
).
__
4
Replace the top cover.
__
5
Place the 600r server in the chosen location and connect
the SCSI terminator (see
"Installing the server" (page 27)
__
Connect the 600r server and devices as follows:
__
•
Connect the monitor, keyboard, and mouse (see
connect the mouse, keyboard, and monitor to the
server" (page 29)
).
__
•
Connect the modem (see
).
__
•
Connect the 600r server to the ELAN Ethernet switch
or hub (see
"To connect the server to the ELAN subnet
(Meridian 1 or CS 1000 only)" (page 32)
Note: If you are connecting the optional Nortel server
subnet, do not connect until you ensure that CallPilot has
the latest antivirus software. Do not install third-party
antivirus software unless approved by Nortel. For
information about the antivirus software packages that
are approved by Nortel for CallPilot, see Product Bulletin
P-2007-0101-Global : CallPilot Support for Anti-Virus
Applications. Also, ensure your CallPilot application
resides behind your network firewall.
__
•
Connect the 600r server to the CLAN Ethernet switch
or hub (optional); (see
Nortel server subnet (optional)" (page 33)
__
•
Install the software feature dongle (see
Nortel software feature dongle" (page 34)
__
6
•
Connect the power cords for all peripheral devices, and
then power them up (see
for power requirements).
__
7
Start the 600r server (see
__
