Server features 13
Clearance • front: 2 inches (50.8 mm)
• rear: 3.6 inches (92 mm)
• side: 1 inch (25 mm)
Weight of fully loaded system with:
• SCSI hard drive
• MPB96 board
• DVD/CD/CDRW drive
approximately 10 kg (23 lbs)
Environmental specifications
Environmental condition Specification
Operating temperature +5 C to +35 C (41 F to 95 F)
Maximum rate of change must not
exceed 10
C (50 F) per hour.
Non-operating (storage) temperature -40 C to +70 C (-40 F to +158 F)
Non-operating humidity 95% @ 23-40 C
Altitude <6000 ft. (1829 m)
Electrostatic discharge <= 15 kV
Acoustic noise < 55 dBA
Operating shock No errors with a half sine wave shock
of 2G (with 1 millisecond duration)
Handling drop 2g 11 mS
18" free-fall when packaged
Front panel features
The following diagram shows the front view of the server chassis with the
bezel cover in place. When the bezel cover is removed, Drive Bay 1 is
accessible.
Nortel CallPilot
600r Server Hardware Installation
NN44200-307 01.03 Standard
5.0 14 May 2008
Copyright © 2007-2008, Nortel Networks
.
