38 Chapter 4 Installing the server and peripheral devices
feature key with the data contact facing down and away from the
embossed i. See
"Installing the. feature key." (page 38) .
Dongle without feature key
3 To eject a software feature key, insert a straightened paper clip into
the side access hole.
a. Push the paper clip in the direction of the software feature key.
Note: In the following figure, label 1 is the data contact, and
label 2 is the ground.
Installing the. feature key.
4 Plug the dongle into USB port 0 on the rear panel of the server.
Note: Due to system driver allocations, the dongle must be
installed in USB port 0.
—End—
