Valid PCI card configurations
17
Note: Your server configuration depends on what was ordered from
Nortel. Therefore, your server may not have all of the slots populated.
When looking at the server from the rear (see
), both full-size and low-profile cards are numbered from
the top down.
Note: There are two MPB96 board versions; the NTRH40AA, and
NTRH40CA. The following table compares the two boards.
Version
Description
NTRH40AA
Has a single DB-44 connector on its faceplate
Connects to the CS 1000 or Meridian 1 with an NTRH2014 DS30X cable
NTRH40CA
Has three RJ-45 connectors on its faceplate
Connects to the CS 1000 or Meridian 1 with three standard RJ-45
connectorized Ethernet cables
For more information about these cables and connecting the NTRH40CA
MPB96 board to MGate cards, see Communication Server and CallPilot
Server Configuration (NN44200-312) or Meridian 1 and CallPilot Server
Configuration (NN44200-302).
ATTENTION
If you have an NTRH40AA MPB96 board, you must connect the DS30X-1 cable
to an MGate card to receive the clock source for the MPB96 board. Failure to
connect the DS30X-1 cable to an MGate card can result in noise interference on
the remaining voice channels. This restriction does not apply to the NTRH40CA
MPB96 board, as it can receive clock source from any of the three DS30 ports.
1005r PCI card slot configurations
Configuration
Card
slot
type
Slot
number
Position
Card type
Meridian 1*/
CS* 1000
FS_PCI-1
top
MPB96
MGate 1, 2, 3
FS_PCI-2
middle
Not used
Full size
FS_PCI-3
bottom
Not used
LP_PCI-1
top
RAID
LP_PCI-2
middle
Dual NIC
Single MPB96
Low profile
LP_PCI-3
bottom
Dual NIC
Note: When cabling to MGate cards, the RJ-45 connectors are numbered from
1 to 3 on the NTRH40CA MPB96 board starting from the right side of the back
panel (next to the power supplies).
