Connecting peripherals to the server
33
To connect the modem to the server
Step
Action
1
Connect one end of the telephone cable to the modem RJ-11 jack
labeled LINE.
2
Connect the other end of the telephone cable to the RJ-11 jack in
the wall.
3
Connect one end of the USB cable into the modem.
4
Connect the other end of the USB cable into either USB port 1 on the
rear panel (long term) or USB port 2 on the front panel (short term).
—End—
To connect the external SCSI tape drive
Step
Action
Note : The external SCSI tape drive is a plug and play device. For a High
availability system you may wish to share one tape drive between the two
servers.
1
Set the SCSI ID dial switch on the tape drive to SCSI ID 6.
2
With the power switch off, connect the external SCSI tape drive to
the port labeled N on the rear panel. See
3
Plug the tape drive into the same single-point ground and A/C power
as the rest of the system.
4
Make sure the SCSI terminator is connected to the tape drive before
powering on the tape drive.
5
Power on the tape unit.
