Page 36

Chapter 4 Installing the server and peripheral devices

—End—

What is next?

IF the server is

THEN

connected to a Nortel server subnet

continue with

"Connecting the server

to the Nortel server subnet (optional)"
(page 36)

not connected to a Nortel server subnet

continue with installing the software
feature dongle. See

"Installing the

Nortel software feature dongle" (page
37)

Connecting the server to the Nortel server subnet (optional)

Introduction

This section provides instructions to connect the server to the Nortel server
subnet.

Note 1: The Nortel server subnet is optional. However, it is required to
support desktop and Web messaging users.

Note 2: If you are installing a High Availability system, do not connect
either sever to the Nortel Server Subnet. The connection to the Nortel
Server Subnet is made when you configure the system.

ATTENTION

To comply with EMC radiation requirements, a Class A Ethernet switch or hub
must be located 10 m (33 ft.) away from the 1005r server. Shielded Ethernet
cables must be used.

To connect the server to the Nortel server subnet

Step

Action

See the diagram on page

"Rear panel connectors" (page 31)

locate the CLAN connection.

Connect an RJ-45 network cable from the Nortel server subnet
Ethernet switch or hub to the CLAN connector.

—End—

Nortel CallPilot

1005r Server Hardware Installation

NN44200-308

01.06

Standard

5.0

15 May 2008
