MCS 5100 RTP Media Portal Basics
57 Copyright © Nortel Networks Limited 2006
Net1 Media IP Type: IP Address
Range: 7-15
characters
Default: 0.0.0.0
The Net1 Media IP address of this
particular media blade. Repeated
for each media blade.
Net2 Media IP Type: IP Address
Range: 7-15
characters
Default: 0.0.0.0
The Net2 Media IP address for
this particular media blade.
Repeated for each media blade.
Number Ports Type: Positive
Integer
Range: 0-65535
Default: 20
Defines the size of the media
resource pool for each media
blade. The value is specified by
System Engineering and based on
call types and traffic patterns. The
default should change in
accordance with the factors
described above.
Blade Name Type: Text
Range:
blade1-blade16
Default: blade1,
blade 2, etc.
String describing this particular
media blade. Repeated for each
media blade.
Note: This field is not
configurable.
Min Port Value Type: Positive
Integer
Range: 0-65535
Default: 40000
Minimum port range value.
Max Port Value Type: Positive
Integer
Range: 0-65535
Default: 60000
Maximum port value.
Table 2 RTP Media Portal tab configurable properties (Sheet 7 of 8)
Configuration property Format Description
(Sheet 7 of 8)
