Tapping a WAN connection
Chapter 2 Installing Your GigaStor
44
rev. 1
Serial
The serial T1/E1 kit includes:
Q
One serial T1/E1 WAN TAP
Q
One serial Y cable
Q
One serial T1 WAN cable
1
If you have a GigaStor Expandable, see “Connecting the GigaStor
Expandable to the expansion units” on page 52 for details about
connecting them. After connecting them, continue with step 2.
2
Connect the TAP to the GigaStor using the serial T1/E1 WAN
cable.
3
Using the serial Y cable, connect it to the TAP and then to your
CSU/DSU and your router.
4
Use the supplied Ethernet cable to connect the network interface
card in the GigaStor to the network.
Now that you have physically connected the cables for the GigaStor,
you must now configure its software. See “Setting the GigaStor’s IP
address” on page 19.
