© National Instruments Corporation
3-1
3
Signal Connections
This chapter describes the signals on the DAQCard-1200 I/O connector.
I/O Connector
Figure 3-1 shows the pin assignments for the DAQCard-1200 I/O
connector. This connector is attached to the ribbon cable that extends from
the PC Card slot when the card is installed and the cable connected.
Warning
Connections, including power signals to ground and vice versa, that exceed any of
the maximum ratings of input or output signals on the DAQCard-1200 can
damage the DAQCard-1200 and the PC. National Instruments is
NOT
liable for any
damages resulting from any such signal connections.
