S P E C I F I C A T I O N S
S - 3
Electrical and Environment
Temperature
(Allowable)
50 - 90.5° F (10 - 32.5° C)
(Storage)
32 - 104° F (0 - 40° C)
Warm-Up
Max. 45 seconds at 73.4° F (23° C)
First Print
15 seconds (using Letter size paper in paper cassette)
Power Source
120V AC 50/60Hz (U.S.A., Canadian Version Only)
Power Consumption
Operating (Copying); 850 W or less (25° C)
Sleep Mode:
9 W or less
Stand by:
60 W or less (25° C)
Noise
Operating:
50 dB A or less
Stand by:
39 dB A or less
Humidity
Operating:
20 to 80% (without condensation)
Storage:
20 to 80% (without condensation)
Dimensions
17.1 x 17.4 x 12.7 inches/(435 x 442 x 323 mm)
Weight
26.4 lbs/(12 kg)
Parallel Interface Specifications
Interface Connector
Printer Side:
Amphenol FCN-685J036-L/X or equivalent
A shielded cable should be used.
Pin Assignment
Pin No.
Signal
Direction
Pin No.
Signal
Direction
1
DATA STROBE
Input
19
0V(S.G.)
-
2
DATA 1
Input
20
0V(S.G.)
-
3
DTAT 2
Input
21
0V(S.G.)
-
4
DATA 3
Input
22
0V(S.G.)
-
5
DATA 4
Input
23
0V(S.G.)
-
6
DATA 5
Input
24
0V(S.G.)
-
7
DATA 6
Input
25
0V(S.G.)
-
8
DATA 7
Input
26
0V(S.G.)
-
9
DATA 8
Input
27
0V(S.G.)
-
10
ACKNLG
Output
28
0V(S.G.)
-
11
BUSY
Output
29
0V(S.G.)
-
12
PE
Output
30
0V(S.G.)
-
13
SLCT
Output
31
INPUT PRIME
Input
14
AUTO FEED
Input
32
FAULT
Output
15
N.C.
-
33
N.C.
-
16
0V (S.G.)
-
34
N.C.
-
17
0V (S.G.)
-
35
N.C.
-
18
+5V
-
36
SLCT IN
Input
