Panasonic KX-HGW600 - Manual (Page 94)

Operating Instructions
94
Port Forwarding
Port Forwarding allows you to view the Network Camera screen on the LAN side from
the PC on the WAN (Internet) side. Enter the port number and the IP address of the
corresponding Network Camera in the Forwarding Port No. and Forwarding IP
Address respectively.
To set up Network Cameras manually
To change the priority
When you add two or more entries, Change of priority appears. Port Forwarding is
processed from the lower entry number to the higher entry number. To change the
priority of the entry number, enter the source entry number in the left data field and the
destination entry number in the right data field. Then click [Move] and [Save]. Click
[Restart Now!] on the Setup Page.
WAN (Internet)
192.168.0.2:10002
Port Forwarding function
vvv.xxx.yyy.zzz:10001 192.168.0.1:10001
Web browser
vvv.xxx.yyy.zzz:10002
