Set u p connecting the kx-hgw600 to a modem – Panasonic KX-HGW600 User Manual
Page 19

Operating Instructions
[For assistance, please call: 1-800-272-7033]
19
Set
u
p
Connecting the KX-HGW600 to a modem
To access the Internet using a CATV/xDSL/optical cable modem, follow the steps below.
1.
Connect the Ethernet cable (with 8-pin RJ-45 connector) to the Ethernet jack of
the modem.
2.
Connect the other end of the Ethernet cable to the WAN jack of the
KX-HGW600.
Note
Some modems may have a polarity switch or need category 5 cross cable
instead of category 5 straight cable. Please refer to the modem’s manual for
more information.
Ethernet jack of the modem
Ethernet cable
(included accessory)
WAN jack
