After completing the connection between the PC and the KX-HGW600, make sure the
PC is turned off and follow the steps below.
1.
Insert the cable clamper into the cable clamper hole of the KX-HGW600 until you
hear a click.
2.
Connect the DC plug of the AC adaptor to the DC IN jack and the AC plug of the
AC adaptor to the power outlet.
Notes
•
AC adaptor is used as the main disconnect device, ensure that the
socket-outlet is located/installed near the equipment and is easily accessible.
•
Use Only with specified Panasonic AC adaptor PQLV12Y.
Cable clamper
(included accessory)
Power Outlet
(AC 120V)
AC adaptor
(included accessory)
DC plug
DC IN jack
