Page 20

Operating Instructions
20
Connecting a PC to the KX-HGW600
Before connecting a PC to the KX-HGW600, make sure Obtain an IP address
automatically is checked in the TCP/IP Properties window on the PC
(
Page 129) and follow the steps below.
1.
Turn off the PC.
2.
Connect the Ethernet cable (customer provided) to one of the LAN 1—4 jacks of
the KX-HGW600.
3.
Connect the other end of the Ethernet cable to the Ethernet jack of the PC.
Note
All Ethernet jacks have an automatic MDI/MDIX feature, which means either a
"straight" or "cross" cable can be used to connect to any jack.
The KX-HGW600 will automatically detect which cable has been inserted.
Ethernet cable
Ethernet jack
LAN1—4 jacks
