1 configuration types – Panasonic KX-HGW600 User Manual
Page 16

Operating Instructions
16
2.1
Configuration Types
The KX-HGW600 is available on a small or large scale network. The main configuration
types are as follows. Make sure which configuration type is required and set up the
KX-HGW600.
Internet Configuration—[Type 1] (
The KX-HGW600 can establish a LAN by connecting to the Internet.
LAN (Intranet) Configuration—[Type 2] (
The KX-HGW600 can establish a LAN by connecting to the other LAN (Intranet).
Notes
•
The KX-HGW600 is a device with two sides: One side is made up of your LAN
(Local Area Network) of each device in your home or office. The other side is the
WAN (Wide Area Network) outside of your home or office.
•
In this manual the CATV/xDSL/optical cable modem is called "Modem".
Modem
CATV
xDSL
Optical cable
Internet
ISP
WAN
LAN
LAN (Intranet)
WAN
LAN
