MH-2001 Multi-Homing Security Gateway User’s Manual
message – . In this case, you are not allowed to modify or remove the setting. You have to remove
the setting in Policy or WAN Group, and then you are allowed to configure the WAN address.
Adding a new WAN Address
Step 1. In the WAN window, click the New Entry button.
Step 2. In
the Add New Address window, enter the settings for a new WAN network address.
Step 3. Click
OK to add the specified WAN network or click Cancel to discard changes.
6.1.4 WAN Group
Entering the WAN Group window
Step 1. Click
the WAN Group under the Address menu bar to enter the WAN window. The current
settings for the WAN network group(s) will appear on the screen.
Definitions:
Name: Name of the WAN group.
Member: Members of the group.
Configure: Configure the settings of WAN group. Click Modify to change the parameters of WAN group Click
Remove to delete the selected group.
If one of the WAN Group has been added to Policy, the Configure column will show the message –
. In this case, you are not allowed to modify or remove the WAN group. You have to remove the
Group in Policy window, and then you are allowed to configure the WAN Group.
- 46 -
