Hardware and Connectivity 37
Getting to Know Your IOLAN
Rack Mount
This section describes the basic components of all rack mount IOLAN models. This example uses the
IOLAN SCS with dual Ethernet and dual AC power.
Console Port/LED View
Serial/Ethernet View
Power ON/OFF
Server LEDs Serial Activity
Console Port
Serial Ports
Dual Ethernet
PCI Card Faceplate
(SCS models only)
Dual AC Power
Reset
