Access control list configuration task list 83
OnSite 2800 Series User Manual 7 • Access control list configuration
Before you begin to enter the commands that create and configure the IP access control list, be sure that you
are clear about what you want to achieve with the list. Consider whether it is better to deny specific accesses
and permit all others or to permit specific accesses and deny all others.
Note Since a single access control list can have multiple filtering criteria
statements, but editing those entries online can be tedious. Therefore,
we recommend editing complex access control lists offline within a
configuration file and downloading the configuration file later via
TFTP to your OnSite device.
Creating an access control list profile and enter configuration mode
This procedure describes how to create an IP access control list and enter access control list configuration mode
Mode: Administrator execution
name is the name by which the access list will be known. Entering this command puts you into access control list
configuration mode where you can enter the individual statements that will make up the access control list.
Use the no form of this command to delete an access control list profile. You cannot delete an access control
list profile if it is currently linked to an interface. When you leave the access control list configuration mode,
the new settings immediately become active.
Example: Create an access control list profile
In the following example the access control list profile named WanRx is created and the shell of the access con-
trol list configuration mode is activated.
2800>enable
2800#configure
2800(cfg)#profile acl WanRx
2800(pf-acl)[WanRx]#
Adding a filter rule to the current access control list profile
The commands permit or deny are used to define an IP filter rule. This procedure describes how to create an
IP access control list entry that permits access
Mode: Profile access control list
This procedure describes how to create an IP access control list entry that denies access
Step Command Purpose
1 node(cfg)#profile acl name Creates the access control list profile name and enters the configura-
tion mode for this list
Step Command Purpose
1 node(pf-acl)[name]#permit ip {src src-wildcard | any |
host src} {dest dest-wildcard | any | host dest} [cos group] Creates an IP access of control list
entry that permits access defined
according to the command
options
