Serial port configuration task list 50
OnSite 2800 Series User Manual 4 • Serial port configuration
Mode: Frame Relay
Example: Entering Frame Relay PVC configuration mode
The following example enters the configuration mode for PVC with the assigned DLCI of 1 for Frame Relay
over the serial interface on slot 0 and port 0 of an OnSite router.
2800(cfg)#port serial 0 0
2800(prt-ser)[0/0]#framerelay
2800(frm-rel)[0/0]#pvc 1
2800(pvc)[1]#
Configuring the PVC encapsulation type
You must use the PVC configuration command encapsulation rfc1490 to set the encapsulation type to com-
ply with the Internet Engineering Task Force (IETF) standard (RFC 1490). Use this keyword when connect-
ing to another vendor’s equipment across a Frame Relay network.
This procedure describes how to set the encapsulation type to comply with RFC 1490
Mode: Frame Relay
Example: Configuring the PVC encapsulation type
The following example sets the encapsulation type to comply with RFC 1490 for PVC with the assigned DLCI
of 1 for Frame Relay over the serial interface on slot 0 and port 0 of an OnSite router.
2800(cfg)#port serial 0 0
2800(prt-ser)[0/0]#framerelay
2800(frm-rel)[0/0]#pvc 1
2800(pvc)[1]#encapsulation rfc1490
Binding the Frame Relay PVC to IP interface
A newly created permanent virtual circuit (PVC) for Frame Relay has to be bound to an IP interface for further
use. The logical IP interface has to be already defined and should be named according to the use of the serial
Step Command Purpose
1 node(frm-rel)[slot/port]#pvc dlci Enters the PVC configuration mode by assigning a DLCI number
to be used on the specified sub interface
Step Command Purpose
1 node(frm-rel)[slot/port]#encapsulation rfc1490 Sets RFC1490 PVC compliant encapsulation
