Ethernet interfaces 121
OnSite 2800 Series User Manual B • Specifications
Ethernet interfaces
10/100Base-TX Ethernet WAN port
4-port 10/100Base-TX Ethernet LAN switch (Model 2805)
10/100Base-TX Ethernet LAN port (all other models)
All ports full duplex, autosensing, auto-MDIX 10/100 Full Duplex/Autosensing Ethernet RJ-45
Sync serial interface
ITU-T X.21 or V.35 interface
Female DB-15 and DB-25 connectors (receptacles)
DTE orientation. (DCE orientation for X.21 is available from the Patton factory upon special request).
T1/E1 interface (Model 2803 only)
• T1: RJ-48C connector (receptacle)
• E1: RJ-48C connector (receptacle) and dual BNC coaxial connectors (receptacles)
• Line Rate
- 1.544 Mbps (T1) in accordance with ANSI T1.403
- 2.048 Mbps (E1) in accordance with ITU-T G.703
• Line Coding
- T1 AMI or B8ZS (default), selectable
- E1 AMI or HDB3 (default), selectable
• Clocking is software selectable as Internal or Network Timing source (default)
• T1 Line Build-out
- Transmit: Selectable for 0, -7.5, -15, -22.5 dB
- Receive: Automatic
• Line Framing
- T1 ESF (default) and unframed
- E1 CRC (default), non-CRC-4, and unframed
• Isolation 1,500 Vrms
PPP support
X.21 or V.35 WAN
Frame-Relay (8 PVCs)
RFC1490, FRF.12 fragmentation
LMI, Q.933D, ANSI 617D, Gang of Four
