Link scheduler configuration task list 111
OnSite 2800 Series User Manual 8 • Link scheduler configuration
The command has optional values (in the range of 1 to 4) that define the level of detail (see table 13 ).
Note The debug features offered by OnSite require the CPU resources of
your OnSite router. Therefore do not enable statistic gathering or
other debug features if it is not necessary. Disable any debug feature
after use with the
no form of the command.
You can enable queue statistics for all queues of a link scheduler by placing the debug queue statistics com-
mand in the profile header. Queue statistics are reset whenever the configuration is changed or OnSite is
reloaded.
Mode: Source
Example: Enable statistics gathering for all queues of a profile
The following example shows how to enable statistic gathering for all traffic-classes
2800>enable
2800#configure
2800(cfg)#profile service-policy sample
2800(pf-srvpl)[sample]#debug queue statistics 4
Table 13. Values defining detail of the queuing statistics
Optional Value Implication on Command Output
0 Statistic gathering is switched off
1 Display amount of packets passed (did
not have to wait), queued (arrived ear-
lier than rate permitted) and discarded
(due to overflowing queue)
2 Also collects byte counts for the catego-
ries listed above
3 Also keeps track of the peek queue
lengths ever reached since the last con-
figuration change or reload
4 Adds delay time monitoring
Step Command Purpose
1 node(src)[name]#debug queue statistics level Enables statistic gathering for the selected class
or policy name. The optional argument level,
which is in the range from 1 to 4, defines the ver-
bosity of the command output.
