OnSite Model 2800 Series overview 20
OnSite 2800 Series User Manual 1 • General information
Figure 3. OnSite 2800 Series 10Base-T Ethernet port connectors
Ethernet WAN models. The following models come equipped with 10/100Base-T Ethernet ports only (see
figure 3 ):
• OnSite 2802—Dual 10/100Base-T Ethernet ports, one for LAN connection and one for connection to
a WAN
• OnSite 2805—Integrated Ethernet switch with four 10/100Base-T Ethernet ports and one 10/100Base-T
Ethernet port for connection to a WAN
• OnSite 2823—Three 10/100 Base-T Ethernet ports with the independent purpose of WAN, LAN, and
DMZ
IPLink 2805 10/100Base-T Ethernet WAN port 0/0
IPLink 2802 10/100Base-T Ethernet ports 0/1 and 0/0
Ethernet LAN ports 0/1 – 0/4
