iCOM
Control Training and Service Manual
Large Display Jumper Settings
Jumper
Type
Setting
P3
Watchdog
* Shunt on Pins 1 & 2
P4
Manual Contrast
(Rev. 1)
* Shunt on Pins 2 & 3
P8 open
*
open
P13
open
* open
P78
CAN Termination
* Shunt on Pins 2 & 3
P82
Watchdog
(Rev. 2 Only)
* Shunt on Pins 1 & 2
P83
Bootloader
* Shunt on Pins 2 & 3
* Default Setting
Small Display DIP Switch #3 Settings
Position
Type
Setting
1 CAN
Address
Off
2
CAN Address
Off
3 CAN
Address
Off
4
CAN Address
Off
5 CAN
Address
On
6
CAN Address
On
7 CAN
Baud
Off
8
CAN Baud
Off
