iCOM
Controls Training and Service Manual
iCOM Control Board Jumper Settings
Jumper
Type
Setting
P19 Watchdog
* On: Shunt on Pins 1 & 2
Off: No Shunt
P78
CAN Bus
Terminator
On: Shunt on Pins 2 & 3
* Off: Shunt on Pins 1 & 2
P83 Bootloader
Enabled: Shunt on Pins 1 & 2
* Disabled: No Shunt
* Default Setting
Large Display DIP Switch #3 Settings
Position
Type
Setting
1 CAN
Address
Off
2
CAN Address
Off
3 CAN
Address
Off
4
CAN Address
Off
5 CAN
Address
Off
6
CAN Address
Off
7 CAN
Baud
Off
8
CAN Baud
Off
