Appendix A: Specifications
Dimensions
Height: 136.5 mm (5.375 in.)
Width: 149.2 mm (5.875 in.)
Depth: 76.2 mm (3.0 in.)
Weight
895 g (1.97 lbs) without lens, battery or power module, or storage media
Image sensor
36 x 24 mm, 12 bit, RGB CMOS Imager
Total pixels: 13.85 million
Effective pixels: 13.7 million
ISO range
160 - 1600 (Raw) in 1/3 EV increments or
160 - 800 (JPEG, or Raw + JPEG) in 1/3 EV increments
Lens mount
CANON EF lenses and CANON tilt and shift lenses. Go to
SIGMA lenses with CANON mount. Go to
Autofocus system
TTL phase difference detection system
Number of focus points
5
Autofocus sensitivity (ISO 100 with
f/1.4)
-1 to 18 EV
Focus lock
Available
Shutter
Vertical-travel metal focal plane shutter, electronically controlled through
entire speed range
Shutter speeds
30 sec. to 1/6000 sec. in 1/3-stop increments, Bulb mode, Flash Sync mode
Maximum flash synchronization speed
1/180 sec.
1/6000 sec. with a high speed flash (FP Flash)
Metering system
TTL full exposure metering
Metering modes
8 Segment, Average, Center Area
