170
Various messages
The message dialog box will disappear when you press the
OK button.
Auto-Punch is not available in MTC Slave/Master mode.
Auto-punch recording cannot be performed if the MIDI
Sync setting is set to MTC Slave or MTC Master.
Battery voltage for Calender is low.
The calendar battery has insufficient voltage.
→ Replace the battery as described in “Replacing the
Cannot have more than 100 Songs.
You cannot exceed maximum of 100 songs on one song
drive.
→ Delete unneeded songs. Be sure to back up any data you
wish to save before deleting it from the hard drive.
Check Sum Error occurred.
The system update has failed.
→ Try the update procedure once again from the
beginning. If this message still appears, please contact
your Korg distributor.
Clock source changed to internal because S/P DIF Error
occurred.
Because the S/P DIF clock could not be detected
correctly, the Word Clock setting Clock Source has been
switched to Internal.
→ Make sure that the signal is being output correctly from
the external device.
→ Make sure that the D32XD/D16XD is correctly
connected with the external device.
→ Make sure that the optical digital cable is not faulty.
Clock source changed to internal because the sampling
frequencies do not match.
Because the external sampling frequency does not match
the sampling frequency of the current song, the Word
Clock
setting Clock Source has been switched to
Internal
.
Completed.
The operation has been completed successfully.
Continuous recording time limit exceeded.
The maximum continuous recording time is 12 hours (6
hours at 96 kHz). It is not possible to continuously
record for longer than this.
Directory Path is too long.
Access is not possible because the directory path is too
long.
→ The D32XD/D16XD cannot access a path that is longer
than 64 characters. Do not create a directory path longer
than 64 characters.
Disc is not CD-RW.
The disc currently in the drive is not a CD-RW.
→ Insert a CD-RW disc.
Disk too busy.
This message will appear if repeated punch-in/out
recording or track editing operations have fragmented
the data on the disk, slowing down access to the hard
drive.
→ In the TRACK, “EditTrk” tab page, execute the
“OptimizeTrk”
operation with “Mode” set to “Normal.”
If this error message still appears even after you execute
“OptimizeTrk,”
go to the SYSTEM, “DiskUtility” tab
page and execute “CheckDrive.”
If “Disk too busy.” appears during playback, execute “Check
Drive”
with “Current Song” selected. If the message appears
during recording, execute “Check Drive” with “Current Parti-
tion”
selected.
In some cases, ultra-low frequencies played back in the studio may
cause “Disk too busy.” messages to appear. In this case, elimi-
nate the problem by relocating the D32XD/D16XD before you ex-
ecute the Check Drive operation.
If the Song Type is 48 kHz/24-bit and you record multiple tracks
(four or more tracks) simultaneously, there is a increased possibil-
ity that the state of the hard disk recording area (i.e., fragmenta-
tion) will cause the “Disk too busy.” message to appear. We
recommend that you always execute “OptimizeTrk” (
ter recording or editing multiple tracks simultaneously in a 48
kHz/24-bit song.
Drive Error occurred.
An error has occurred while accessing the drive.
→ If this message appears while you are working on a song
drive, execute “Check Drive.” If the message still
appears after executing this, format the drive.
→ If this message appears while you are working on the PC
drive, format the PC drive.
→ If this message appears while you are working on the
CD drive, use a different disc. If the message still
appears, it is possible that the CD-R/RW drive has
malfunctioned. Please contact your Korg distributor.
Exceeds drive capacity.
There is not enough free space on the drive.
→ If this message appears while you are working on a song
drive, you can either delete the Undo data or delete
unneeded songs. Alternatively, you can use a different
song drive.
→ If this message appears while you are working on the PC
drive, delete unneeded files or folders.
Exp/Cmp ratio is out of range.
The expansion/compression ratio used in the
“ExpCmpTrk”
track edit operation is beyond the
allowable range. The maximum expansion is double, and
the maximum compression is half. Change the settings
of the TO and END locations.
Failed to receive MIDI data.
Reception of MIDI data has failed.
Failed to write CD.
Writing to the CD-R/RW disc has failed.
→ Refer to the “Troubleshooting” section on CD-R/RW.
Failed to write System.
System updating has failed.
→ It is possible that the D32XD/D16XD has malfunctioned.
Please contact your Korg distributor.
