■ Principal specifications
■ Analog/digital input and output spec-
ifications
Display:
320
× 240 pixel, four-level grayscale
Movable LCD with backlight and touch
panel
Power supply:
AC Local Voltage
Power consumption:
D32XD
: 98 W
120 W
(AIB-8, ACB-8, DIB-8 is installed)
D16XD
: 56 W
70 W
(AIB-8, ACB-8, DIB-8 is installed)
Dimensions:
682 mm (W)
× 474 mm (D) × 185 mm (H)
26.85" (W)
× 18.66" (D) × 7.28" (H) (including
protrusions)
Weight:
D32XD
13.5 kg/39.76 lbs
14 kg/30.86 lbs (
when the AIB-8, ACB-8
and DIB-8 is installed
)
D16XD
12 kg/26.46 lbs
12.5 kg/27.56 lbs (
when the AIB-8, ACB-8
and DIB-8 is installed
)
Frequency response:
10 Hz – 20 kHz ±1 dB
@ fs 44.1 kHz, +4 dBu, 10 k
Ω load
10 Hz – 22 kHz ±1 dB
@ fs 48 kHz, +4 dBu, 10 k
Ω load
10 Hz – 44 kHz ±1 dB
@ fs 96 kHz, +4 dBu, 10 k
Ω load
S/N:
103 dB (typical)
Dynamic range:
103 dB (typical)
THD+N:
0.02% (typical) 20 Hz–20 kHz
+16 dBu,10 k
Ω load
A/D conversion:
24-bit 64 times oversampling
D/A conversion:
24-bit 128 times oversampling
Sampling frequency
Internal: 44.1 kHz, 48 kHz, 96 kHz
External: 44.1 kHz±6%, 48 kHz±6%,
96 kHz±6%
Record/Playback bit:
16-bit, 24-bit
Connectors:
XLR-3-31 type (+48 V phantom power,
switchable), 1/4" TRS phone jack (balanced)
Input impedance:
4 k
Ω (XLR-3-31), 10 kΩ (TRS phone jacks)
Nominal level:
–60 dBu to –12 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Maximum level:
–48 dBu to 0 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +26 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600
Ω
* If the 8-channel analog input board (AIB-8) is installed
Connectors:
1/4" TRS phone jack (balanced)
Input impedance:
10 k
Ω
Nominal level:
–60 dBu to –12 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Maximum level:
–48 dBu to 0 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +12 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600
Ω
Threshold level:
0 to –40 dB
Ratio:
1.5:1 to inf:1
Attack time:
1 to 200 mS
Release time:
10 mS to 10 S
Out gain:
±20 dB
Connector:
1/4" phone jack (unbalanced)
Input impedance:
1 M
Ω
Nominal level:
–60 dBu to –12 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Maximum level:
–48 dBu to 0 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +12 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600
Ω
Connectors:
1/4" phone jack (balanced)
Output impedance: 150
Ω
Nominal level:
+4 dBu
Maximum level:
+16 dBu
Load impedance:
10 k
Ω or higher
