Adjusting Print Image Position
25
1
Adjusting Print Image Position
You can adjust the print image posi-
tion to suit your needs.
*…Paper feed direction
A
Press the
[Image
=
=
=
=
]
key.
Note
❒ You can skip step
A and adjust
the image position directly by
pressing the
{~}, {}}, {|}, and
{{} keys.
B
Adjust image position using the
{{{{~
~
~
~}}}}, {{{{}
}
}
}}}}}, {{{{|
|
|
|}}}}, and {{{{{
{
{
{}}}} keys.
Note
❒ When you shift the image for-
wards, leave a 10 mm, 0.4" mar-
gin at the leading edge. If there
is no margin, paper might wrap
around the drum and cause a
misfeed.
❒ The
{~} and {}} keys shift the
image up to 15 mm, 0.6" each
way and the image is shifted
about 0.5 mm, 0.02" each time
they are pressed.
❒ The
{|} and {{} keys shift the
image up to 10 mm, 0.4" each
way and the image is shifted
about 0.5 mm, 0.02" each time
they are pressed.
C
Press the
[OK]
key.
D
Press the
{{{{
Proof
}}}} key to check the
image position.
GRPOSI0E
TPES560E
ow
Fast
Speed
Clear/S
TPES090N
Program
Clear Modes
Auto Cycle
Proof
Enter
Start
Clear/Stop
TPES060N
