Chapter 2: Installation
2-19
USB Wake-Up (*USB1/2
Only)
Use JPUSB1 to enable or disable
USB Wake-Up, which allows you
t o w a k e u p t h e s y s t e m b y d e -
pressing a key on the keyboard or
by clicking the mouse when either
is connected to the USB1 or USB2
port. Enable the jumper a to allow
the system to be woken up from
S1 and S3 in Windows OS. See
the table on the right for jumper
settings.
Jumper
Position
1-2
2-3
Definition
VCC5V
USB Wake-Up
Jumper Settings (JPUSB1)
VCC5V
Standby
Marvell's SATA Enable
(*P4SCT+/P4SCT+II Only)
JPS1 is used to enable or disable
Marvell's Serial ATA Controller.
See the table on right for pin defi-
nitions. Intel's Serial ATA Control-
ler is enabled or disabled via the
BIOS.
Jumper
Position
1-2
2-3
Definition
Disabled
Enabled
Marvell's SATA Enable
Jumper Settings (JPS1)
(P4SCT+/P4SCT+II Only)
