Ethernet Ports GLAN1 and
GLAN2 (*P4SCT/P4SCT+II
only)
Two Eth ernet ports
(designated GLAN1 and
GLAN2) are located beside the
VGA port on the IO backplane.
These ports accept RJ45 type
cables.
VGA Connector
A VGA connector (JG1) is
located next to the GLAN1 on
the IO backplane. Refer to the
board layout below for the
location.
SMB Header
A S y s t e m M a n a g e m e n t B u s
header is located at J15. Connect
the appropriate cable here to uti-
lize SMB on your system.
SMB Header
Pin Definitions (J15)
Pin
Number
1
2
3
4
Definition
Data
Ground
Clock
No Connection
