Connecting Cables
Power Supply Connectors
The primary power supply
connector (J20) on the P4SCT/
P4SCT+/P4SCT+II meets the SSI
(Superset ATX) 24-pin specifica-
tion. Refer to the table on the
right for the pin definitions of the
ATX 20-pin power connector.
You must also connect the 4-pin
(J21) processor power connector
to your power supply. Refer to
the table below right for the J21
(12V) connector. (*You must use
J21 for CPU Power.)
Pins #
1 & 2
3 & 4
Definition
Ground
+12 V
+12V 4-pin
Connector
(J21)
Required
Connection
PW_ON Connector
The PW_ON connector is located
on pins 1 and 2 of JF1.
Pin
Number
1
2
Definition
PW _ON
+3V
PW_ON
Pin Definitions
(JF1)
ATX Power Supply 24-pin Connector
Pin Definitions (J20)
Pin Number Definition
13
+3.3V
14
-12V
15
COM
16
PS_ON#
17
COM
18
COM
19
COM
20
Res(NC)
21
+5V
22
+5V
23
+5V
24
COM
Pin Number Definition
1 +3.3V
2 +3.3V
3 COM
4 +5V
5 COM
6 +5V
7 COM
8 PWR_OK
9
5VSB
10
+12V
11
+12V
12
+3.3V
CPU
