Samsung M6000 User’s Manual Using the SmartBay 26
Using the SmartBay
Your computer includes the SmartBay™, a peripheral bay that can
hold one of the following devices:
Floppy drive: shipped installed in your computer.
CD-ROM drive: shipped with some M6000 Series computers.
Optional secondary hard drive: available as an option for your
computer.
Make sure that the computer’s power is off
before you remove or install a device in the
SmartBay.
To remove a device from the SmartBay:
1. Turn the computer’s power off.
2. Close the LCD panel, and turn the computer over so that the
bottom of the unit faces up.
3. Pull up on the SmartBay latch (Figure 12). The device in the
SmartBay pops partially out of the bay.
Figure 12. Removing a Device from the SmartBay
4. Pull the device out of the bay.
To install a device in the SmartBay:
Bottom of
computer
SmartBay latch
