For Machines Mfg. Since 5/11 13" x 40" Heavy 13 ® EVS Lathe
-97-
E L E C T R I C A L
Work
Light
Chuck Guard
Safety Switch
End Cover
Safety Switch
Brake Switch
9
0
1
A1
0 2
COM
NO
NC
NC NO
3
NC
14 22
13 21
NO
4
5
3
A1
Additional Component Wiring
Power Supply Connection (PS)
Ground
Hot
Hot
Hot
Master Power
Switch
220VAC 15-20 Plug
(As Recommended)
HOT HOT HOT
6T3 N
N
4T2 2T1
5L3 3L2 1L1
Figure 147. Chuck guard safety switch.
Chuck Guard
Safety
Switch
To Electrical Cabinet Terminal Board
(Page 92)
Figure 146. End gear cover safety switch and RPM
sensor.
RPM Sensor
End Gear
Cover Safety
Switch
