-100-
For Machines Mfg. Since 5/11 13" x 40" Heavy 13 ® EVS Lathe P A R T S
Headstock Controls Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
6 PW04M FLAT WASHER 10MM 48 PSB10510048 SHIFT LEVER BRACKET
7 PSB10510007 FEED DIRECTION SHIFT FORK 49 PCAP24M CAP SCREW M5-.8 X 16
9 PEC015M E-CLIP 8MM 50 PSB10510050 SHIFT LEVER
20 PCAP17M CAP SCREW M4-.7 X 10 51 PSB10510051 COMPRESSION SPRING
21 PSB10510021 GEAR 40T 52 PSB10510052 LEVER FLAT WASHER 5MM
22 PSB10510022 SPEED RANGE SELECTOR BRACKET 53 PLW05M LOCK WASHER 12MM
23 PCAP02M CAP SCREW M6-1 X 20 54 PCAP92M CAP SCREW M12-1.75 X 40
24 PORP044 O-RING 43.7 X 3.5 P44 55 PSB10510055 OIL SIGHT GLASS 3/4"
25 PSB10510025 SPEED RANGE SELECTOR BASE 56 PSB10510056 ALIGNMENT SHAFT
26 PCAP50M CAP SCREW M5-.8 X 10 57 PORP014 O-RING 13.8 X 2.4 P14
27 PSB10510027 SPEED RANGE SELECTOR LEVER 58 PSB10510058 SHIFT ARM
28 PSTB001 STEEL BALL 1/4" 59 PR06M EXT RETAINING RING 16MM
29 PSB10510029 COMPRESSION SPRING 60 PSB10510060 SPEED RANGE SHIFT FORK
30 PSS20M SET SCREW M8-1.25 X 8 149 PSB10510149 HEADSTOCK FRONT PANEL
31 PSB10510031 SPEED RANGE SELECTOR HUB 150 PSB10510150 OIL DISTRIBUTOR BRACKET
34 PK101M KEY 6 X 6 X 14 151 PFH71M FLAT HD CAP SCR M5-.8 X 8
35 PSB10510035 CONTROL HUB SHAFT 152 PSB10510152 OIL TUBE SUPPORT BRACKET
36 PORP018 O-RING 17.8 X 2.4 P18 153 PSB10510153 OIL DISTRIBUTOR
37 PSB10510037 HUB FLAT WASHER 6MM 154 PSB10510154 NYLON OIL TUBE 10MM
38 PCAP01M CAP SCREW M6-1 X 16 155 PSB10510155 PIPE JOINT 3/8 NPT
39 PSB10510039 END PLUG 156 PCAP15M CAP SCREW M5-.8 X 20
40 PSB10510040 COMPRESSION SPRING 157 PSB10510157 TUBE CLIP
41 PSB10510041 GEARBOX RANGE SHIFT FORK 158 PS05M PHLP HD SCR M5-.8 X 8
42 PR05M EXT RETAINING RING 15MM 159 PSB10510159 OIL TUBE 4 X 415MM
43 PSB10510043 PIVOT ARM 160 PSB10510160 OIL TUBE 4 X 370MM
44 PK155M KEY 3 X 3 X 18 161 PSB10510161 OIL TUBE 4 X 215MM
45 PSB10510045 FEED DIRECTION SHIFT SHAFT 162 PSB10510162 OIL TUBE 4 X 320MM
46 PSB10510046 GEARBOX RANGE SHIFT SHAFT 163 PSB10510163 OIL TUBE 4 X 355MM
47 PORP016 O-RING 15.8 X 2.4 P16 164 PSB10510164 OIL TUBE 4 X 125MM
