Headstock Lubrication System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1201 PSB10511201 OIL TUBE ELBOW ADAPATER 3/8"PT X M6-1 1225 PSB10511225 LUBRICATION MOTOR 1/4HP 220V 3PH
1202 PSB10511202 OIL TUBE SEAL 1225-1 PSB10511225-1 MOTOR FAN COVER
1203 PSB10511203 OIL TUBE SEAL NUT 1225-2 PSB10511225-2 MOTOR FAN
1204 PCAP50M CAP SCREW M5-.8 X 10 1225-3 PSB10511225-3 MOTOR JUNCTION BOX
1205 PW02M FLAT WASHER 5MM 1225-4 PSB10511225-4 MOTOR FRONT BEARING
1206 PSB10511206 CORD CLAMP 10MM 1225-5 PSB10511225-5 MOTOR REAR BEARING
1207 PSB10511207 RPM SENSOR BRACKET 1226 PSB10511226 PIPE ELBOW 1/4"PT X 1/4"PT
1208 PS34 PHLP HD SCR M3-.5 X 25 1227 PSB10511227 STAND PIPE SEAL
1209 PSB10511209 RPM SENSOR FQP2-1604N-3U2 1228 PSB10511228 STAND PIPE W/FILTER 3/8PT X 9-1/2"
1210 PN07M HEX NUT M3-.5 1229 PSB10511229 OIL TUBE 10 X 100MM NYLON
1214 PSB10511214 OIL FILTER 1230 PSB10511230 OIL FILL CAP
1215 PSB10511215 HOSE CLAMP 1-1/2" 1231 PSB10511231 OIL SIGHT GLASS ASSEMBLY
1216 PSB10511216 OIL DRAIN HOSE 1-1/4" X 17" 1232 PSB10511232 PIPE PLUG 3/4PT
1217 PCAP02M CAP SCREW M6-1 X 20 1233 PSB10511233 OIL TANK
1218 PN01M HEX NUT M6-1 1234 PW03M FLAT WASHER 6MM
1219 PCAP04M CAP SCREW M6-1 X 10 1235 PCAP01M CAP SCREW M6-1 X 16
1220 PSB10511220 OIL TANK ACCESS COVER 1236 PCAP14M CAP SCREW M8-1.25 X 20
1221 PSB10511221 OIL PRESSURE SENSOR 1237 PW01M FLAT WASHER 8MM
1222 PSB10511222 PIPE T-JOINT 1/4"PT 1238 PN03M HEX NUT M8-1.25
1223 PSB10511223 PIPE UNION 1/4"PT X 1/4"PT 1239 PSB10511239 ELECTRICAL CABINET W/DOOR ASSY
1224 PSB10511224 LUBRICATION PUMP AM6
