-60-
For Machines Mfg. Since 5/11
13" x 40" Heavy 13
®
EVS Lathe
A C C E S S O R I E S
SB1298—SBL Bench Lathe Shop Clock
SB1299—SBL Toolroom Lathe Shop Clock
SB1300—SBL Lathe with Man
These fine traditional shop clocks are constructed
with a metal antique-finished frame. They are
easy to read from a distance and measure 14"
in diameter. Pictures just don't do them justice.
They are very nice quality clocks and perfect for
the South Bend Lathe aficionado.
Figure 91. Antique-finished South Bend shop clocks.
SB1298
SB1299
SB1300
Keyless Integral Chucks
SB1379—MT #3
1
⁄
2
"
SB1380—MT #3
5
⁄
8
"
These keyless chucks are produced with an
integral shank to maximize concentricity
between the body, shank, and jaws. They start as
a one-piece high-alloy body which is turned, then
finish ground throughout, making them as close
to zero TIR (Total Indicated Runout) as can be.
Keyless chuck self-tightens, so a spanner wrench
is provided to ease tool removal.
Figure 90. MT #3 Keyless Chuck.
SB1238—High Performance MT#3 Live Center
•
Shafts are made of alloy steel and vacuum
heat-treated to HRC60°±1 for high rigidity
and durability.
•
Centers use a combination of roller bearings,
thrust bearings, and ball bearings.
• Waterproof
design.
Figure 92. SB1238 High Performance Live Center.
SB1246—MT#3 Bull Nose Center
•
Cr-Mo steel; hardened to HRC60 ± 1
•
Taper roller & ball bearing construction
•
Great for turning pipes
Figure 93. SB1246 MT#3 Bull Nose Center.
70°
2.05"
3.39"
6.14"
0.71"
3.07"
0.59"
