P A R T S
Bed & Shafts Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
801 PSB10510801 BED 837 PSB10510836A TAPERED BUSHING
802 PSB10510802 CARRIAGE STOP BOLT 838 PSB10510836A TAPER PIN #4 X 1-1/4"
803 PB24M HEX BOLT M12-1.75 X 45 839 P51203 THRUST BEARING 51203
804 PW06M FLAT WASHER 12MM 840 PK20M KEY 5 X 5 X 15
805 PCAP02M CAP SCREW M6-1 X 20 841 PSB10510841 SPRING COVER
806 PRP93M ROLL PIN 6 X 25 842 PSB10510842 COMPRESSION SPRING
807 PSB10510807 LEADSCREW LOCK NUT 843 PR37M EXT RETAINING RING 32MM
808 PSS03M SET SCREW M6-1 X 8 844 PSB10121234 SHEAR PIN
809 P51203 THRUST BEARING 51203 845 PSB10510845 SHEAR PIN SHROUD
810 PSB10510810 SHAFT END BRACKET 846 PSB10510846 LEADSCREW COLLAR
811 PLUBE001 TAP-IN BALL OILER 1/4" 847 PSS02M SET SCREW M6-1 X 6
812 PSB10510812 CASTING PLUG 848 PSB10510848 COMPRESSION SPRING 8 X 32
813 PSS15M SET SCREW M12-1.75 X 12 849 PSB10510849 BED RACK
814 PSB10510814 COMPRESSION SPRING 850 PSB10510850 GAP RACK
815 PSTB003 STEEL BALL 3/8" 851 PSS14M SET SCREW M8-1.25 X 12
816 PCAP40M CAP SCREW M8-1.25 X 35 852 PSB10510852 CAPTIVE PIN
817 PSB10390817 TAPER PIN #6 X 2 853 PSB10510853 PIVOT ARM
818 PSB10510818 LEVER KNOB 854 PEC09M E-CLIP 6MM
819 PSB10510819 SPINDLE LEVER 855 PSB10510855 SPINDLE ROD LINKAGE SHAFT
820 PN09M HEX NUT M12-1.75 856 PSB10510856 SPINDLE SWITCH BRACKET
821 PSB10510821 STEP PIN 857 PSB10490857 MICRO SWITCH TEND TM-1308
822 PSB10510822 THRUST WASHER NTB/AS2 1831 858 PCAP01M CAP SCREW M6-1 X 16
823 PSB10510823 SPINDLE LEVER HUB 859 PSB10510859 LOCK COLLAR
824 PSB10510824 LOCK COLLAR 860 PCAP04M CAP SCREW M6-1 X 10
825 PSS03M SET SCREW M6-1 X 8 861 PS68M PHLP HD SCR M6-1 X 10
826 PSB10510826 LONGITUDINAL LEADSCREW 862 PSB10510862 SPINDLE SWITCH COVER
827 PSB10510827 FEED ROD 863 PSB10510863 HALOGEN LAMP ASSEMBLY
828 PSB10510828 SPINDLE LEVER INDENT BRACKET 863-1 PSB10510863-1 LAMP BODY
829 PSB10510829 SPINDLE ROD SLEEVE 863-2 PBULB3 HALOGEN BULB 24V
830 PSB10510830 COMPRESSION SPRING 863-3 PSB10510863-3 LENS
831 PSB10510831 SPRING COVER 863-4 PSB10510863-4 LENS RETAINER
832 PR37M EXT RETAINING RING 32MM 863-5 PS55M PHLP HD SCR M3-.5 X 10
833 PSB10510833 SPINDLE ROD 863-6 PSB10510863-6 LAMP TERMINAL BLOCK 2P
834 PSB10510834 FEED ROD STOP 864 PCAP64M CAP SCREW M10-1.5 X 25
835 PCAP02M CAP SCREW M6-1 X 20 865 PSB10510865 GAP INSERT THREADED TAPER PIN
836A PSB10510836A CLUTCH COLLAR ASSEMBLY 866 PN03M HEX NUT M8-1.25
836 PSB10510836A CLUTCH COLLAR 867 PSB10510867 GAP INSERT
